Rev. 3/6/2017 CBFC, manual.doc
Copyright 2017 Vestil Manufacturing Co. Page 8 of 13
FIG. 3B: CBFC-2000 rated loads for specified boom lengths
Although the outer boom has only one set of pin holes, the inner boom has 3 sets to allow boom length to be
adjusted. Boom length increases in 12 inch increments. Boom length determines the maximum rated load of the
crane, which decreases as boom length increases as indicated in the table below:
Boom length Maximum rated load
39
1
/
4
inches 2000 lb. (909.1kg)
51
1
/
4
inches 1500 lb. (681.8kg)
63
1
/
4
inches 1000 lb. (454.5kg)
NOTE: DO NOT use the crane unless the inner and outer booms are securely pinned together.
