PARKING BRAKE
This product is equipped with a parking brake. This brake should only be applied when the unit is
stopped. Do not use the parking brake to slow the unit.
1. To apply the brake, pull the brake lever up.
2. Push the brake release button to disengage the brake.
NOTE: ONLY park the mover on level ground.
Unload the hydraulic system when you are finished using the truck by lowering the carriage all the way.
DISENGAGING THE TRANSMISSION (NEUTRAL MODE)
The unit can be moved manually by putting the transmission into
neutral. This decouples the drive wheels from the transaxle. To put the
transmission into neutral:
1. Locate the transaxle release lever.
2. Push the lever in and down until it seats inside the release bracket.
To put the transmission back into drive mode, lift the lever and pull it towards you.
RECORD OF SATISFACTORY CONDITION
Before using the product for the first time, make a record of its appearance and functions. Cycle the
carriage/forks up and down. Describe the motion (e.g. smooth and at a uniform rate). Drive the unit in
forward and in reverse. Describe the motion. Thoroughly photograph the unit from multiple angles
including all labeling applied to it. Each feature listed in the INSPECTIONS AND MAINTENANCE section
Inspect the following components should be photographed in detail. Describe where each label is
located. Collate all photographs and writings into a file. Mark the file appropriately to identify it. This files is
a record of the truck in satisfactory condition. Compare the results of all inspections to this record to
determine if the unit is still in satisfactory condition. Do not use it unless it is in satisfactory condition. Purely
cosmetic changes, like damaged paint/powder coat do not constitute changes from normal condition.
However, touchup paint should be applied to all affected areas as soon as damage occurs. Contact
Technical Service (contact information appears on the cover page) if you have questions that are not
addressed in these instructions.
INSPECTIONS AND MAINTENANCE
Proper maintenance is essential to keep this product in satisfactory condition and to
maximize the service life of the unit.
o DO NOT fill the hydraulic system with brake fluid or jack oils. Only use anti-wear hydraulic oil, viscosity
grade 150 SUS at 100°F (ISO 32cSt at 40°C) or Dexron transmission fluid.
o Fill the engine with oil and gasoline as instructed in the manufacturer’s manual. Perform maintenance
on the engine as directed in that manual.
Transaxle release lever
Drive mode: axle
engaged (as shown in
diagram below: )
Neutral mode: axle
disengaged (push lever
forward and down to
lock)
Parking brake lever
