To reposition a full-height bracket:

1. Loosen the screws in the top and bottom PDU hanging bracket.

2. Slide the bracket along the frame member to the desired location and tighten the screws.

To remove a full-height bracket:

1. Loosen the screws in the top and bottom PDU hanging bracket.

2. Lift the bracket up until the hanging bracket clears the frame member and remove the bracket from the rack.

Figure 4.10 PDU-bracket Features

Item Description

1 Velcro or cable-tie features

2 Tool-less accessory mounting holes

3 Tool-less accessory mounting holes

4 Rack-PDUmounting keyholes

4 Installation and Assembly Procedures

19

Vertiv™ VR Installer/User Guide
