3. Press [UP] or [DOWN] to select the required value and conrm the selection

with [SET].

The following values are available:

Menu level 3 Description

‘DMX’ The device is controlled by a DMX controller.

‘Host’ The device can be controlled manually.

For operation with a DMX controller, it is necessary to set a DMX address.

1. Open the main menu.

2. Navigate to ‘Dmx Address’.

3. Press [UP] or [DOWN] to select a value between 1 and 512 for the desired DMX

address (display shows ‘000’ … ‘512’ ) and conrm the selection with [SET].

Make sure that this number matches the conguration of your DMX controller.

The following table shows the respective highest possible DMX address for the

various DMX modes.

Mode Highest possible DMX address

9-channel mode 504

34-channel mode 479

23-channel mode 490

51-channel mode 462

For operation with a DMX controller, it is necessary to set a DMX mode.

1. Open the main menu.

Navigate to ‘Fixture è Dmx Mode’.

3. Press [UP] or [DOWN] to select the desired DMX mode and conrm the selec‐

tion with [SET].

The following DMX modes are available:

Name Description

‘9CH’ 9-channel mode

‘34CH’ 34-channel mode

‘23CH’ 23-channel mode

‘51CH’ 51-channel mode

You can specify how the device should behave in case of DMX signal loss.

1. Open the main menu.

Navigate to ‘Fixture è Dmx Signal’.

Setting the DMX address

Setting the DMX mode

Setting DMX signal mode

Operating

Hero Pixel Wash 760FX

Moving Head
