7 Operating

7.1 Starting the device

CAUTION!

Risk of injury due to unexpected movements of the device!

The device head may perform fast movements and generate very bright

light. This is the case immediately after the device is switched on, in

automatic or remote operation, and when a connected DMX controller

is switched o. Persons who are in the immediate vicinity of the device

may be injured or frightened by this.

Make sure that there are no obstacles within the movement range of

the mirror, and that no persons are in the immediate vicinity of the head

before switching it on and during its operation.

Switch o the device before any work is performed in the movement

range or immediate vicinity of the device, or if unauthorised persons are

in that area.

Connect the device to the power supply to start operation. After a few seconds, the

fans start to work, and the head moves to the home positions for rotation (pan) and

inclination (tilt). After a few more seconds, the display shows ‘001’ . The device is now

operational.

7.2 Main menu

1. Press [SET] to enter the main menu.

2. To scroll between the individual menu items, press [UP] and [DOWN].

3. To open the selected menu item or conrm a value in a menu, press [SET].

All previous settings are retained even when you switch the device o and

disconnect it from the mains.

4. To exit a menu item without making changes, press [ESC].

If you don't press any button for 30 seconds the display turns o. A short

press on [ESC], [SET], [UP] or [DOWN] will then turn it back on.

7.3 Device settings

The device can be operated with a DMX controller or as an independent host.

1. Open the main menu.

Navigate to ‘Fixture è Run Mode’.

How to use the main menu

Operating mode

Operating

Hero Pixel Wash 760FX

Moving Head
