3. Press [UP] or [DOWN] to select the required value and conrm the selection

with [SET].

The following values are available:

Menu level 3 Description

‘Clear’ If the DMX control fails, the device is blacked out.

‘Hold’ If the DMX control fails, the last setting is retained.

You can specify how the device should behave for pan and tilt inversion.

1. Open the main menu.

2. Navigate to ‘Fixture’.

3. Press [UP] or [DOWN] to select the desired submenu or the desired value and

conrm the selection with [SET].

The following submenus and values are available:

Menu level 2 Menu level 3 Description

‘Pan Invert’ ‘Close’ Pan reversal in opposite direction of

rotation is activated.

‘Open’ Pan reversal in normal direction of

rotation is activated.

‘Tilt Invert’ ‘Close’ Tilt reversal in opposite direction of

rotation is activated.

‘Open’ Tilt reversal in normal direction of rota‐

tion is activated.

Manual control is only possible and relevant if the device is not controlled via a DMX

controller and not working as a slave in a master/slave conguration. Manual control

can be used to adjust pan and tilt.

1. Open the main menu.

2. Navigate to ‘Manual’.

3. Press [UP] or [DOWN] to select the desired submenu or the desired value and

conrm the selection with [SET].

The following submenus and values are available:

Menu level 2 Menu level 3 Description

‘Pan’ ‘000…255’ Adjusts the rotation angle.

‘Pan Fine’ ‘000…255’ Adjusts the ne range of the rotation

angle.

‘Tilt’ ‘000…255’ Adjusts the tilt angle.

‘Tilt Fine’ ‘000…255’ Adjusts the ne range of the tilt angle.

Specifying pan and tilt invert

Manual control

Operating

Hero Pixel Wash 760FX

Moving Head
