UsEr manUaL
www.Vari-LitE.com
VL800 EVEntprofiLE
9
TABLE 1. 16-BIT ENHANCED
DMX PARAMETER DEFAULTS RANGE DESCRIPTION
16 Gobo Wheel 1 0
0 - 255
8-bit control of Gobo Wheel 1. See Channel 20 for control options.
Interchangeable glass gobos
0 - 5 Open - No Gobo
6 - 10 Gobo 1 (Night Sky) Index
11 - 15 Gobo 2 (Circle of Ovals) Index
16 - 20 Gobo 3 (Bricked Out) Index
21 - 25 Gobo 4 (Neurons) Index
26 - 30 Gobo 5 (Swirl) Index
31 - 35 Gobo 6 (Crossed-Bars) Index
36 - 40 Gobo 7 (On the Rock) Index
41 - 45 Open - No Gobo
46 - 50 Gobo 1 (Night Sky) Rotate
51 - 55 Gobo 2 (Circle of Ovals) Rotate
56 - 60 Gobo 3 (Bricked Out) Rotate
61 - 65 Gobo 4 (Neurons) Rotate
66 - 70 Gobo 5 (Swirl) Rotate
71 - 75 Gobo 6 (Crossed-Bars) Rotate
76 - 80 Gobo 7 (On the Rock) Rotate
81 - 85 Open - No Gobo
86 - 90 Gobo 1 (Night Sky) Rotate with Mega Stepping
91 - 95 Gobo 2 (Circle of Ovals) Rotate with Mega Stepping
96 - 100 Gobo 3 (Bricked Out) Rotate with Mega Stepping
101 - 105 Gobo 4 (Neurons) Rotate with Mega Stepping
106 - 110 Gobo 5 (Swirl) Rotate with Mega Stepping
111 - 115 Gobo 6 (Crossed-Bars) Rotate with Mega Stepping
116 - 120 Gobo 7 (On the Rock) Rotate with Mega Stepping
121 - 255 Reserved Values
17
Gobo 1 Rot/Index
High Byte
32767
0 - 65535 16-bit control of index and rotation of gobo wheel 1.
0 - 32756 Rotate Fast to Slow <<<
18
Gobo 1 Rot/Index
Low Byte
32757 - 32780 Rotation STOP
32781 - 65535 Rotate Slow to Fast >>>
19
Gobo Wheel 1
Control
0
0 - 255
Used as a control channel for dierent movement options for Gobo
Wheel 1 (Channel 17)
0 - 5 Gobo Selection using shortest (quickest) path.
6 - 10 Gobo Selection using normal (longest) path.
11 - 20 Reserved Values
21 - 50 Wheel Spin CW Forward (Fast to Slow)
51 - 60 Wheel Spin STOP
61 - 90 Wheel Spin CCW Reverse (Slow to Fast)
91 - 120
Gobo Shake Quickest Path (Slow to Fast) For fastest shake set
gobo timing to 0
121 - 150
Gobo Shake Normal Path (Slow to Fast) For fastest shake set gobo
timing to 0
151 - 180
Gobo Twist Quickest Path (Slow to Fast) For fastest twist set gobo
timing to 0
181 - 210
Gobo Twist Normal Path (Slow to Fast) For fastest twist set gobo
timing to 0
211 - 255 Reserved Values
