UsEr manUaL
www.Vari-LitE.com
VL800 EVEntprofiLE
8
DMX CHANNELS
CHANNEL MAPPING
The following tables assumes a DMX start address of 1. When a dierent starting address is used, this address
becomes channel 1 function and other functions follow in sequence.
TABLE 1. 16-BIT ENHANCED
DMX PARAMETER DEFAULTS RANGE DESCRIPTION
1 Intensity High
0 0-65535 16-bit control of Dimming
2 Intensity Low
3 Pan High
32767 0-65535 540° Total Pan Rotation
4 Pan Low
5 Tilt High
32767 0-65535 270° Total Tilt
6 Tilt Low
7 Focus High
32767 0-65535
Focus control
Default value 50% Focus range
8 Focus Low
9 Zoom High 128 0-255
Zoom control
Default value 50% zoom range
10 Cyan 0 0 - 255 Cyan Color Control 0-100% saturation
11 Yellow 0 0 - 255 Yellow Color Control 0-100% saturation
12 Magenta 0 0 - 255 Magenta Color Control 0-100% saturation
13 CTO 0 0 - 255 CTO Color correction Control 0-100% saturation
14 Color Wheel 0
0 - 255
8-bit control of Color Wheel.
(spin speed slow to fast from control channel)
OPEN (centered at 0)
0-31 Open
32-63 VL RED Centre - 48
64-95 Dark Blue Centre - 80
96-127 Yellow Centre - 112
128-159 Kelly Green Centre - 144
160-191 Amber Centre 176
192-223 Congo Blue Centre 208
224-255 Open
15
Color Wheel
Control
0
0 - 255
0 - 5 Linear Movement using shortest (quickest) path.
6 - 10 Linear Movement using normal (longest) path.
11 - 15 Wheel Spin CW (Forward)
16 - 20 Wheel Spin STOP
21 - 25 Wheel Spin CCW (Reverse)
26 - 56
Color Shake Quickest Path (Slow to Fast) For fastest shake set color
timing to 0
57 - 87
Color Shake Normal Path (Slow to Fast) For fastest shake set color
timing to 0
88 - 255 Reserved Values
3
