UsEr manUaL
www.Vari-LitE.com
VL800 EVEntprofiLE
10
TABLE 1. 16-BIT ENHANCED
DMX PARAMETER DEFAULTS RANGE DESCRIPTION
20
Gobo Wheel 2
(Fixed)
0
0-255
8-bit control of Gobo Wheel for movement options see channel 22
Single metal stamped wheel
0-25 Open - No Gobo
26-51 Gobo 1 (Leafy Breakup)
52-77 Gobo 2 (Honeycomb)
78-103 Gobo 3 (Radial Breakup)
104-129 Gobo 4 (Grid)
130-155 Gobo 5 (Circle of dots)
156-181 Gobo 6 (Punchcard)
182-207 Gobo 7 (Vertical bars)
208-233 Gobo 8 (Medium Circle)
234 - 255 Open - No Gobo
21
Gobo Wheel 2
Control
0
0 - 255
Used as a control channel for dierent movement options for Gobo
Wheel 2 (Channel 21)
0 - 5 Gobo Selection using shortest (quickest) path.
6 - 10 Gobo Selection using normal (longest) path.
11 - 20 Reserved Values
21 - 50 Wheel Spin CW Forward (Fast to Slow)
51 - 60 Wheel Spin STOP
61 - 90 Wheel Spin CCW Reverse (Slow to Fast)
91 - 120
Gobo Shake Quickest Path (Slow to Fast) For fastest shake set
gobo timing to 0
121 - 150
Gobo Shake Normal Path (Slow to Fast) For fastest shake set gobo
timing to 0
151 - 180 Reserved Values
181 - 210 Reserved Values
211 - 255 Reserved Values
22 Iris 0
0-255 Iris size control
0 - 200 Iris beam size open to closed
201 - 255 Iris pulse slow to fast
23 Frame 1A 0 0 - 255 Controls Framing Shutter 1A from Open to Full (DMX 0-255).
24 Frame 1B 0 0 - 255 Controls Framing Shutter 1B from Open to Full (DMX 0-255).
25 Frame 2A 0 0 - 255 Controls Framing Shutter 2A from Open to Full (DMX 0-255).
26 Frame 2B 0 0 - 255 Controls Framing Shutter 2B from Open to Full (DMX 0-255).
27 Frame 3A 0 0 - 255 Controls Framing Shutter 3A from Open to Full (DMX 0-255).
28 Frame 3B 0 0 - 255 Controls Framing Shutter 3B from Open to Full (DMX 0-255).
29 Frame 4A 0 0 - 255 Controls Framing Shutter 4A from Open to Full (DMX 0-255).
30 Frame 4B 0 0 - 255 Controls Framing Shutter 4B from Open to Full (DMX 0-255).
31 Frame Rotate 128 0 - 255 Controls Framing Shutter mechanism from +/- 90°
32 Triangular Prism 0 - 255
0 - 255 Controls Prism mechanism with following values.
0 - 5 Open
6 - 10 Index
11 - 15 Rotate Normal
16 - 20 Rotate with Mega Stepping
21 - 255 Reserved Values
