Je bekijkt pagina 34 van 48
USER MANUAL
WWW.VARI-LITE.COM
VL5LED WASH
34
TABLE 11. DMX MAP FOR STROBE
DMX LED
GROUP
PARAMETER DEFAULT RANGE DESCRIPTION
116
22 22 Strobe / Shutter 33
0 - 5 Shutter Closed
6 - 11 Shutter Open (Default 33)
12 -87 Strobe Slow>>>>>>>Fast
88 - 93 Strobe Open
94 - 169 Strobe Random Slow>>>>>>>>Fast
170 - 245 Strobe Random Sync Slow>>>>>>>>Fast
246 - 251 Shutter Open
252 - 255 Reserved
TABLE 12. BEAM CONTROL
DMX LED
GROUP
PARAMETER DEFAULT RANGE DESCRIPTION
116
27 27 Beam Timing 255 0-255 See timing table
TIMING
TIMING CHANNEL INFORMATION
Timing channel control improves the timed moves of certain groups of parameters. We provide up to three tim-
ing channels - Focus (pan and tilt), Color Time (color parameters), and Beam Time (beam parameters).
Types of timing control:
• Timing Control Channel: the luminaire uses its timing channel value to calculate a smooth continuous
movement for a given time and transition.
• Console Timing: the console calculates the time duration between the DMX increments to be sent for a
given time and transition.
GUIDELINES:
• Timing channels support time values of up to six minutes.
• To use a timing channel instead of console timing, it is necessary to set the timing channel to the
desired value and set cue and/or parameter time to zero. A combination of time controls can produce
unexpected results.
• The default value setting in the profi le should be 255 (proportional control) to allow smooth movement
when using console timing.
• The timing channel data should change as a snap. A zero value will give the fastest move, however,
without any smoothing this can appear “steppy” in console timed moves.
NOTE: Some parameters have been excluded from the timing channels. Wheel spin and gobo rotation rate
changes are not a ected by timing channels.
TABLE 13. CHANNEL FUNCTION / TIMING CHANNEL RELATIONSHIP
DMX LED
GROUP
PARAMETER DEFAULT RANGE DESCRIPTION
116
25 25 Focus Timing 255 0 - 255 See timing table
26 26 Color Timing 255 0 - 255 See timing table
27 27 Beam Timing 255 0 - 255 See timing table
A timing value of zero is full speed. A time value of 100% (or DMX 255) enables the associated parameter(s) to
follow cue fade time (console time) rather than the timing channel.
