USER MANUAL
WWW.VARI-LITE.COM
VL5LED WASH
33
To use control channel functions:
Step 1. Select an action to be sent.
Step 2. Set control channel value for desired action (for example, 6 for ReCal). Hold value for 3 seconds.
Step 3. Set control channel value to zero. (This must occur without any scaling values. Action will be voided if
other values are detected between action value and zero.)
NOTE: A numerical keypad is suggested for sending values. An encoder or fader does not allow for a quick
value change, which is required to e ect the control functions.
TABLE 9. CTO
CTO LEVEL
LED OUTPUT LEVEL % CIE 1931 COORDINATES
R G B A L C X Y
1800k 100.00% 0.00% 1.95% 100.00% 23.35% 0.00% 0.5464 0.404
2700K 100.00% 0.00% 11.07% 100.00% 63.35% 0.00% 0.4566 0.4055
3000K 100.00% 0.00% 17.56% 100.00% 79.71% 0.00% 0.4321 0.3942
3200K (Default) 100.00% 0.00% 19.75% 100.00% 86.74% 0.00% 0.4224 0.3958
4000K 100.00% 36.05% 37.27% 100.00% 100.00% 0.00% 0.3776 0.3671
4500K 99.99% 69.86% 43.15% 100.00% 100.00% 0.00% 0.361 0.3654
5000K 100.00% 100.00% 50.39% 100.00% 100.00% 6.08% 0.3456 0.3596
5600K 100.00% 100.00% 58.76% 100.00% 100.00% 52.98% 0.3304 0.3483
6500K 100.00% 100.00% 72.49% 100.00% 100.00% 99.13% 0.3126 0.3298
8000K 82.78% 100.00% 92.09% 100.00% 100.00% 100.00% 0.2945 0.3058
10000K 81.66% 100.00% 99.99% 27.94% 100.00% 100.00% 0.2783 0.293
COLOR MIXING
The color mixing mechanism is made up of six graduated color fl ags: red, green, blue, amber, lime and cyan.
These fl ags provide full-spectrum color cross fades from pastel to saturated color.
TABLE 10. DMX MAP FOR RED, GREEN, BLUE, AMBER, LIME, AND CYAN
DMX LED
GROUP
PARAMETER DEFAULT RANGE DESCRIPTION
116
8 8 Red (High)
0 0-65535 0 - 100% linear control of Red LED output
9 9 Red (Low)
10 10 Green (High)
0 0-65535 0 - 100% linear control of Green LED output
11 11 Green (Low)
12 12 Blue (High)
0 0-65535 0 - 100% linear control of Blue LED output
13 13 Blue (Low)
14 14 Amber (High)
0 0-65535 0 - 100% linear control of Amber LED output
15 15 Amber (Low)
16 16 Lime (High)
0 0-65535 0 - 100% linear control of Lime LED output
17 17 Lime (Low)
18 18 Cyan (High)
0 0-65535 0 - 100% linear control of Cyan LED output
19 19 Cyan (Low)
