USER MANUAL
WWW.VARI-LITE.COM
VL5LED WASH
32
TABLE 8. PROGRAMMERS CHANNEL
DMX Items DESCRIPTION
POWER
CYCLE
RULES
RECAL
RULES
REST TO
DEFAULT
FIXTURE
RESET TO
DEFAULT
UI
FUNCTION
SELECTION
VIA UI
116 - 120
Studio Mode
- Reduced
output with
lower fan
settings
Studio Mode - Fan speed reduced
to appropriate amount to reduce
dB levels >10% of full speed + LED
@ max output approximately 80%
of Standard output at appropriate
level to ensure LED work at optimum
temperature and output effi ciency
*Fans can be switched between
Continous (136-140) or Auto (141-
145)
Hold
Setting
Hold
Setting
Resets to
Default
Resets to
Default
Yes
121 - 125
Whisper Mode
- Reduced
output with
lower fan
settings
Whisper mode - Fan speed reduced
to appropriate amount to reduce dB
levels to >30% of the full speed +
LED Max output approximately 60%
of Standard output at appropriate
level to ensure LED work at optimum
temperature and output effi ciency
*Fans can be switched between
Continous (136-140) or Auto (141-
145)
Hold
Setting
Hold
Setting
Resets to
Default
Resets to
Default
Yes
126 - 130
Reserved
Values
N/A N/A N/A N/A N/A
131 - 135
Record User
Color Preset
Takes Current Color mixing values
and stores to next available blank
User color preset - if preset listing
are full preset will not record. User
will need to clear preset via fi xture UI
N/A N/A N/A N/A N/A
136 - 140
Fan On
(Default)
Fans run at continuous speed in
isolation to the LED operating
temperature
Hold
Setting
Hold
Setting
Resets to
Default
Resets to
Default
Yes
141 - 145 Fan Auto
Fans will reduce / increase speed
on demand based on LED operating
temperature
Hold
Setting
Hold
Setting
Resets to
Default
Resets to
Default
Yes
146 - 150
Reserved
Values
N/A
Hold
Setting
Resets to
Default
Resets to
Default
Yes
151 - 155 ReCal Position Recalibration of Positions N/A
Hold
Setting
Resets to
Default
Resets to
Default
Yes
156 - 160
Reserved
Values
N/A
Hold
Setting
Resets to
Default
Resets to
Default
Yes
161 - 165 ReCal Beam Recalibration of all Beam function N/A
Hold
Setting
Resets to
Default
Resets to
Default
Yes
166 - 170
Reserved
Values
N/A
Hold
Setting
Resets to
Default
Resets to
Default
Yes
171 - 175
Reset fi xture
to default
Will reset all parameters to default
with the exception of the DMX
address fi xture mode
N/A N/A N/A N/A Yes
176 - 255
Reserved
Values
N/A
Hold
Setting
Resets to
Default
Resets to
Default
Yes
