RJ45 NETWORK
CONNECTION
SIDE
HORN SIGNAL CONNECTION
HORN
RJ45 NETWORK
CONNECTION
SIDE
STANDARD
RJ45 PATCH CABLE
(T568B)
Typical 568B
RJ-45 Jack
RJ-45
CAT 3/5/6
VM-186
RJ45
WHITE/GREEN
GREEN
WHITE/BROWN
BROWN
BROWN
BLUE
WHITE/BLUE
BLUE
WHITE/ORANGE
ORANGE
WHITE/GREEN
GREEN
WHITE/BROWN
BROWN
WHITE/BLUE
BLUE
WHITE/ORANGE
ORANGE
HORN
*The Maximum Recommended Distance
From the IP Link to the Horn is 350’.
TECHNICAL ASSISTANCE
Assistance is available from the factory.
Call (540) 563-2000 and press 1 for Technical
Support or visit our website at
http://www.valcom.com.
Warranty
Warranty information may be found on our website
at www.valcom.com/warranty
Valcom equipment is not field repairable. Valcom,
Inc. maintains service facilities in Roanoke, VA .
Should repairs be necessary, attach a tag to the
unit clearly stating your company name, address,
phone number, contact person and the nature of
the problem. Send the unit to:
Valcom, Inc.
Repair & Return Dept.
5614 Hollins Road
Roanoke, VA 24019-5056
Information provided is subject to change
Typical Connection
Extended Wiring Connection
