26
Table 2-10 Technical parameters
ITEM
Specification Condition
01
Part No.
HY22580HA2B-C
02
Dimension
225×225×80mm
03
Rated Voltage
220VAC 50/60Hz
04
Operating Voltage
70~260 VAC
a. Rated Voltage
b. 25℃
c. 65%RH
d. Measured after 5 Mins
05
Rated Current
0.30/0.34 A
±10%
06
Rated Power
65/75 W
±10%
07
Rated Speed
2530/2800 RPM
±10%
08
Max.Airflow
637 CFM
a. Rated Voltage
b. Rated Current
c. P&Q
d. Stand:AMCA
1080 m³/H
09
Max.Static Pressure
197 Pa
0.79 InchH2O
10
No.of Blade
9
11
Noise Level
59 dB(A)
a. Rated Voltage
b. Non-Echo Chamber
c. Distance:1.0M
12
Life Expectancy
60000Hrs at 25℃
a. Rated Voltage
b. L10 at Conf.Level 90%
13
Rotating Direction
Clockwise(From Label side)
14
IP Level
IP55
15
Motor Type
Capacitor motor
16
Type of protection
Thermal protection
17
Weight
2200g
The temperature setting for turning the fan on/off can be adjusted according to the actual situation.
