08Safety
User Manual
•
When accessing the internal circuit of inverter, it is very important to
wait 5 minutes before operating the power circuit. Do not open the
device barehanded.
•
Measure the voltage between terminals DC+ and DC- with a
multi-meter (impedance at least 1Mohm) to ensure that the device is
discharged before beginning work (35VDC) inside the device.
•
Testing to AS/NZS 4777.2:2020 to multiple inverter combinations
has not been conducted So multiple phase inverter combinations
should not be used or external devices should be used in accordance
with the requirements of AS/NZS 4777.1.
•
•
Islanding effect is a special phenomenon that grid-connected PV
system still supply power to the nearby grid when the voltage loss is
happened in the grid system. It is dangerous for maintenance person -
nel and the public. HiEnergy series inverter provide Active Frequency
Drift (AFD) to prevent islanding effect.
The end-use application shall monitor the protective conductor by
residual current operated protective device (RCD) with rated fault
current I
fn
of a fault.
The device is intended to connect to a PV string with a capacitance
limit of about 700nf.
Warning!
Warning!
High leakage current!
Ground the system before power on.
