17
TD-001538-01-A1
Command Response Description
lss.sys.capture_audio_sync_delay|Flash to
Pop Delay|0|100
0.000000
Instructs the LSS-200 to capture the current sync delay (ms from flash to pop)
to its log. The parameters are description, min, and max. Returns the latest delay
measurement in ms. Note that this is the delay measured at the LSS-200 and is only
valid during the playback of a flash/pop sync test.
lss.sys.capture_audio_sync_delay_at_
screen|Flash to Pop Delay at Screen|0|100
0.000000
Instructs the LSS-200 to capture the current sync delay (ms from flash to pop)
to its log. The parameters are description, min, and max. Returns the latest delay
measurement in ms. Note that this is the delay at the screen calculated based on the
delay measured at the LSS-200 and the distance from the LSS-200 to the screen
as entered during LSS-200 configuration. This is only valid during the playback of a
flash/pop sync test.
lss.sys.capture_audio_sync_delay_at_
smpte|Flash to Pop Delay at SMPTE reference
position|0|100
0.000000
Instructs the LSS-200 to capture the current sync delay (ms from flash to pop)
to its log. The parameters are description, min, and max. Returns the latest delay
measurement in ms. Note that this delay is at the SMPTE reference position (2/3 way
from screen to LSS-200) based on the LSS-200 to screen distance entred during
LSS-200 configuration. This is only vlaid during the playback of a flash/pop sync test.
lss.sys.capture_spl|SPL Center Low|81.2|83.2 83.239520
Instructs the LSS-200 to capture the current SPL to its log. The parameters are
description, min, and max. Returns the current SPL in dBc.
lss.sys.capture_fl|Luminance|13|15 14.1234
Instructs the LSS-200 to capture the luminance (measured in fL) to its log. The
parameters are description, min, and max.
lss.sys.capture_cdm2|Luminance|47|49 48.4321
Instructs the LSS-200 to capture the luminance (measured in cd/m
2
) to its log. The
parameters are description, min, and max.
lss.sys.capture_cct|Color
Temperature|6100|6300
6262
Instructs the LSS-200 to capture the correlated color temperature in Kelvin to its log.
The parameters are description, min, and max
lss.sys.capture_temperature_
c|Temperature|20|40
25
Instructs the LSS-200 to capture its internal temperature in Celcius to its log. The
parameters are description, min, and max.
lss.sys.capture_temperature_
f|Temperature|60|80
70
Instructs the LSS-200 to capture its internal temperature in Fahrenheit to its log. The
parameters are description, min, and max.
lss.sys.capture_x|Color|0.308|0.320 0.314
Instructs the LSS-200 to capture the color coordinate x. The parameters are
description, Xmin, Xmax.
lss.sys.capture_y|Color|0.345|0.357 0.351
Instructs the LSS-200 to capture the color coordinate y. The parameters are
description, Ymin, Ymax.
lss.sys.cp850_test_start|0|192.168.1.146
Sends a command to a Dolby® CP850 to output a test signal to the specified speaker
(0-63). The first parameter is the speaker number. The second parameter is the IP
address of the CP850. The IP address is only required on the first test_start command
sent to the CP850. If it is omitted, test_start commands will be sent to the same CP850.
lss.sys.cp_850_test_stop
Stops the test signal generation in the Dolby CP850 and returns it to normal
operation.
lss.sys.log_post|http://lssdb.uslinc.com/post.
php
lss.sys.log_post| http://user:pw@example.
com:1234/path/filename
Posts logs in XML to the specified URL. The URL can be HTTP or HTTPS. The URL can
include a username, password, and port number, if desired. Posts all log data since
the last log post to this URL. If more than one post is included in a script, add a wait of
120 seconds between posts to allow time for the first to complete.
lss.sys.tcp_send_string|address|port|string
lss.sys.tcp_send_string|192.168.1.123|10001
|jsd60.sys.fader\t700\r
Allows a user to have the LSS-200 relay a TCP string to another device. The first
argument is the IP address to send the string to. The second argument is the port
number. The third argument is the string to send. The string being sent can include
control characters generated by an escape sequence. The sample sends a carriage
return (\r) at the end of the string. Permitted escape sequences are:
\\ = backslash
\t = tab
\n = newline
\r = carriage return
\a = alarm (bell)
\f = form feed
\v = vertical tab
\b = backspace
lss.sys.script_run|0 Runs the specified script. If no script number is specified, runs script 0 (the first one).
lss.sys.script_wait|30
Causes a script to wait the specified number of seconds before executing the next
line. Waits between captures keeps the measurement capture synchronized with the
test content.
