19
Rrs+
Right Rear Surround+
20
R-
Right-
21
22
GND
23
Ls+
Left Surround+
24
Rs+
Right Surround+
25
LFE+
Low Frequency Effects+
Crossover Analog Audio Outputs
With the crossover option board installed, additional outputs are available on an additional
DB25M connector. This connector has the high band and a LFE2 outputs. The low bands and
surround channels are on the main audio output connector.
Signals Listed By Channels
Audio
Channel
DB25M Crossover
Output Pins (+, -, shield)
Left High
2, 14, 1
Center High
5, 17, 4
Right High
8, 20, 7
LFE 2
25, 12, 13
Signals Listed By Connector Pins
DB25F Pin
Out
Signal Name
Channel Name
1
GND
2
Lh+
Left High+
3
4
GND
5
Ch+
Center High+
6
7
GND
8
Rh+
Right High+
9
GND
10
11
12
LFE2-
Low Frequency Effects 2-
13
GND
14
Lh-
Left High-
15
GND
16
