184050 Page 33
17
Ch-
Center High-
18
GND
19
20
Rh-
Right High-
21
22
GND
23
24
25
LFE2+
Low Frequency Effects 2+
AES/EBU Outputs
If the JSD-60 has an AES/EBU output board (JSD-60S, JSD-60DS), AES/EBU audio output is
available on a pair of RJ-45 connectors. The pin out is described in the tables below.
Left AES/EBU Output Jack Signals Listed By Channels
Audio
Channels
AES/EBU
Pair
RJ-45 Pins (+, -)
Speakers
1, 2
1
1, 2
Left/Right (low band if bi-amp)
3, 4
2
3, 6
Center/LFE1
5, 6
3
4, 5
Left High Band/Right High Band+ if bi-amp
7, 8
4
7, 8
Center High Band/LFE2+ if bi-amp
Left AES/EBU Output Jack Signals Listed By Connector Pins
RJ-45
AES/EBU
Signal Name
Channel Name
1
1/2+
Left/Right+ (low band if bi-amp)
2
1/2-
Left/Right- (low band if bi-amp)
3
3/4+
Center/LFE1+
4
5/6+
Left High Band/Right High Band+ if bi-amp
5
5/6-
Left High Band/Right High Band- if bi-amp
6
3/4-
Center/LFE1-
7
7/8+
Center High Band/LFE2+ if bi-amp
8
7/8-
Center High Band/LFE2- if bi-amp
Right AES/EBU Output Jack Signals Listed By Channels
Audio
Channels
AES/EBU
Pair
RJ-45 Pins (+, -)
Speakers
9,10
1
1, 2
Ls/Rs
11,12
2
3, 6
Not Used
13,14
3
4, 5
Lrs/Rrs
15,16
4
7, 8
Not Used
