184050 Page 31
Audio Channels Full Range and Crossover
Audio Channel
DB25M Main Output Pins (+, -, shield)
Left
2, 14, 1
Center
5, 17, 4
Right
8, 20, 7
LFE
25, 12, 13
Ls
23, 10, 22
Rs
24, 11, 9
Lrs/Lc
16, 3, 15
Rrs/Rc
19, 6, 18
When the channel configuration is “Drive In,” the outputs and their use are listed in the
following table.
Audio Channels Drive In
Audio Channel
DB25M Main Output Pins (+, -, shield)
Left Transmit
2, 14, 1
Right Transmit
8, 20, 7
Field
23, 10, 22
Snack Bar
24, 11, 9
Monitor
16, 3, 15
Signals Listed By Connector Pins
DB25M Pin
Signal Name
Channel Name
1
GND
2
L+
Left+
3
Lrs-
Left Rear Surround-
4
GND
5
C+
Center+
6
Rrs-
Right Rear Surround-
7
GND
8
R+
Right+
9
GND
10
Ls-
Left Surround-
11
Rs-
Right Surround-
12
LFE-
Low Frequency Effects-
13
GND
14
L-
Left-
15
GND
16
Lrs+
Left Rear Surround+
17
C-
Center-
18
GND
