Signals Listed By Channels
Signals Listed By Connector Pins
DB25F Pin
Signal Name
Channel Name
1
GND
2
L+
Left+
3
4
GND
5
C+
Center+
6
7
GND
8
R+
Right+
9
GND
10
Ls-
Left Surround-
11
Rs-
Right Surround-
12
LFE-
Low Frequency Effects-
13
GND
14
L-
Left-
15
GND
16
17
C-
Center-
18
GND
19
20
R-
Right-
21
GND
22
GND
23
Ls+
Left Surround+
24
Rs+
Right Surround+
25
LFE+
Low Frequency Effects+
Eight Channel Analog Main Audio Outputs
The main outputs drive a DB25M that is marked “8 Channel Analog Output” for full range audio
and the low band stage outputs for bi-amp.
Channel Number
DB25F PINS ( +, -, shield )
Speakers
1
2, 14, 1
Left
2
8, 20, 7
Right
3
5, 17, 4
Center
4
25, 12, 13
LFE
5
23, 10, 22
Ls
6
24, 11, 9
Rs
