GB/IE/NI
17
Flash mode
To switch the LED light
7
on in flash or SOS mode, press the power switch
7a
for the LED light.
The LED light
7
will then be permanently lit.
Briefly press the power switch for the LED light
7a
once again and the LED light
7
will switch to flash
mode.
Briefly press the power switch for the LED light
7a
once again and the LED light
7
will switch to SOS
mode. There will be 3 short flashes, 3 long flashes and another 3 short flashes.
Briefly press the power switch
7a
for the LED light once again to switch off the LED light
7
.
CAUTION! Do not look directly at the LED light
7
as this can damage your eyes.
PLEASE NOTE: It is not possible to turn on the light while the power bank with compressor
1
is
charging.
z Using the jumpstart feature
When using the jumpstart, make sure that at least 3 bars are permanently illuminated on the battery
level indicator
13
.
1
B A
2. 1.
Step LEDs Meaning / Error Solution
1. Connect the jump
lead
18
of the power
bank with compressor
1
to the vehicle
jumpstart outlet
8
of
the power bank with
compressor
1
.
Red Error LED
20
on the jump
lead
18
is permanently lit.
A short alarm will sound once
a second.
The voltage determined in the
power bank with compressor
1
is not enough to start the
car.
Charge the power bank with
compressor
1
.
Green Start LED
19
flashes.
Power bank with compressor
1
ready.
Carry on with step 2
2. First connect the
red clamp (A) to the
positive pole of the
vehicle battery and
then connect the black
battery clamp (B) to
the negative pole
(see Fig. 1).
Red Error LED
20
on the jump
lead
18
is permanently lit.
A short alarm will sound twice
a second.
Battery clips (A) and (B) are
the wrong way round.
Disconnect the black battery
clip (B) first and then the red clip
(A) from the battery poles.
Start again from step 1.
Red Error LED
20
on the jump
lead
18
is permanently lit.
An alarm will sound several
times a second in quick
succession.
A short circuit has occurred or
the battery is leaking.
Green Start LED
19
is
permanently lit.
The connection is correct. Carry on with step 3.
Once the green Start LED
19
has remained permanently lit
for more than 90 seconds, then
the red Error LED
20
and green
Start LED
12
will be
permanently lit.
The connection is correct,
however because the vehicle
was not started within
90 seconds, the jumpstart
procedure was stopped for
safety reasons.
Disconnect the black battery
clip (B) first and then the red clip
(A) from the battery poles.
Start again from step 1.
