18
GB/IE/NI
3. Start up the
vehicle.
Red Error LED
20
on the jump
lead
18
is permanently lit.
A short alarm will sound once
a second.
The temperature is too high,
possibly due to several jump
start attempts.
Disconnect the
black battery clip (B) first and
then the red clip (A) from the
battery poles. Start again from
step 1.
Red Error LED
20
and green
Start LED
19
are permanently lit.
The starting procedure has
failed.
The starting procedure was
successful.
The motor is running.
ATTENTION: As soon as the vehicle starts, remove the jump lead
18
from the power bank with
compressor
1
within 30 seconds and firstly disconnect the black battery clip (B) and then the red
clip (A) from the battery poles. Otherwise, it could result in dangerous situations!
Leave the vehicle engine running.
z FAQ
Q: Question
A: Answer
Q: How long does it take to fully charge a mobile phone with the device?
A: With a rechargeable battery capacity of 3500 mAh: Approx. 3–4 hours if connected to the USB
output 5V
/1A
12
. Approx. 2–3 hours if connected to the USB output 5V /2 A
11
. Please note
that if the device is switched on, it will continually use battery power while actually charging and this
can extend the charging time.
Q: How long does the power bank with compressor
1
hold a full charge?
A: 3–6 months. However, we recommend recharging the rechargeable battery pack monthly.
Q: How is the power bank with compressor
1
switched off?
A: After switching on the power bank with compressor
1
with the power bank switch
9
, the power
bank with compressor switches off automatically after approximately 20 seconds if the compressor is not
started or if no consumables are connected. It is not possible to switch the device off manually.
z Troubleshooting
= problem
= cause
= remedy
The power bank with compressor
1
is not fully charged, even though all 4 bars on
the battery level indicator
13
are permanently lit.
It is 60% charged after a long period out of use or in storage.
Recharge the power bank with compressor
1
as described in the section “Charging the power bank
with compressor”.
Power bank does not respond when power bank switch
9
is pressed.
Deep discharge protection active on the power bank with compressor
1
.
Recharge the power bank with compressor
1
.
One bar on the battery level indicator
13
is flashing, however the power bank with
compressor
1
cannot be used.
Deep discharge protection active on the power bank with compressor
1
.
Recharge the power bank with compressor
1
.
