32 tvONE
This parameter has three possible states: On, Off and Auto. On and off manually control the Ethernet
capability of the unit. When in Auto mode, if a valid Ethernet connection is present, remote control of the
unit will automatically default to Ethernet and control via RS-232 is disabled whilst that connection is
maintained.
Enter 4 numbers one by one to form the IP address you wish to assign to the unit. The IP address is a
series of four numbers between 0 and 255. Anything above 255 is not a valid number in an IP address
range. The unit will not allow you to go above 255.
The IP address must be a unique address on your network, and also must be within the sub-net of your
network. If you are unsure about which IP address to use or don’t have a unique IP address, ask your
Network Administrator.
Adjust the last 2 numbers to set the sub-net address (also know as sub-net mask) of your network. Again,
if in doubt ask your Network Administrator.
Enter your network’s gateway IP address into this menu item. Again, if in doubt ask your Network
Administrator. In general, the gateway only needs setting if the unit is being controlled from a different
network (e.g. via the internet).
Enter the IP port number you wish the unit to communicate on. Keep a note of this as it will be needed
when using other devices to communicate with the unit e.g. CC-300.
Certain units require a re-boot once the new IP address has been entered. Once activated, all current
settings (including other menu items) will be saved and the unit will re-boot. If you do not see this menu
item, then your unit has already implemented your changes and no re-boot is required.
Adjust ethernet
IP enabled [Auto]
Adjust Ethernet
IP add. [ 10] 1 2 123
Adjust Ethernet
IP sub. 255.255. [255.000]
Adjust Ethernet
IP gtwy. [ 10] 1 2 123
Adjust Ethernet
IP port [10001]
1A Adjust Ethernet
Set new IP data & reboot
