MNL- C2-6204-V3.00 31
By default, the following are assigned:
Tally input pin
pulled low
Preset loaded
TI1
1
TI2
2
TI3
3
TI4
4
TI5
5
TI6
6
TI7
7
TI8
8
The adjust Ethernet menu
(Please note that not all units have this sub-menu.)
Your unit can be remotely controlled via its RS-232 serial port, but some units can also be controlled via a
Local Area Network using the Ethernet connector. This provides TCP/IP communications to and from the
unit using a custom protocol.
In most networks, all computers and other electronic equipment will have a dedicated connection to a
network hub or switch, with each item having its own ‘IP address’ (Internet Protocol address). This is the
unique set of numbers that identifies the item on the network.
The network itself is usually segmented into a number of sub-networks. Small offices will generally just
use one sub-network, with larger ones running many sub-networks that are linked together across a sub-
network bridge. Sub-networks are split up by assigning different ranges of IP addresses to the different
sub-networks. The ranges are defined by the ‘sub-net mask’.
In very simple setups with 2 pieces of equipment (e.g. a computer and one other piece of equipment), it is
possible to link the two together using just a cable (which must be a cross-over cable). However, this
setup is rare.
Where only a single sub-network exists (as in the majority of cases) it is vital that:
1. All equipment has different IP addresses.
2. All IP addresses are part of the same sub-net.
3. All equipment has the same sub-net mask.
In most situations the computer will already be attached to a network, and therefore its IP address and
sub-net mask will be easily accessible (e.g. in Windows XP you can right-click on the network activity icon
to see the Support status, or check the Network Connections in the Control Panel and right-click the ‘Local
Area Connection’).
An IP Address then needs to be assigned to your unit. Typically this will be by changing the last of the 4
values (that are separated by dots) to one that is not yet in use. The ‘IP add’ menu item is used to enter
this into your unit.
The sub-network’s ‘sub-net mask’ then needs to be copied to the ‘IP sub’ menu item listed below.
For simple setups (where only a single sub-network is in use), there is no need to change the IP gtwy
(gateway) numbers.
