MNL- C2-6204-V3.00 33
The adjust resolutions menu
The Resolution Database is used by your unit to identify any incoming video signal and is also used to
create an output resolution. It is therefore a very important part of the unit’s infrastructure.
Important Cautionary Information
Do not adjust these items unless you’re certain you know what you’re doing. The only method to undo
certain changes is to update the firmware.
Try using autoset, shrink, shrink pos, tl & br adjustments first.
Making adjustments here risks creating a non-standard resolution that is not displayable on a monitor.
The resolutions and values within the database are industry standards and should not normally be altered
by the user. That said, there might be times when it is necessary to create a custom resolution with
specific parameters. If circumstances require you to make such a change, please read the following
specific notes:
• Any changes made to this database take effect instantly and are also stored immediately in non-
volatile memory.
• Since this database is used for both input and output image processing, altering a resolution that
is used for both (e.g. 1024x768 input and 1024x768 output) may give undesired effects.
Change the value to select resolution you want to alter.
Note: typically, the image number currently being used for input or output would be already be selected.
Otherwise immediate feedback to your changes will not be available via your monitor.
This adjustment specifies whether the image is interlaced or progressive scan. It toggles simply On or Off,
so there are no flashing brackets.
Course Frequency Adjust
The H freq.crse (Horizontal Sync Frequency - Course) adjustment provides the option for changing the
Horizontal Sync timing Frequency in 100 Hz steps.
Fine Frequency Adjust
The H.freq.fine (Horizontal Sync Frequency) adjustment provides the option for changing the Horizontal
Sync timing Frequency in 1 Hz steps. Use this option to fine tune after using the course adjust.
Please note that the internal sync generator may be unable to generate the exact frequency you want.
800 x 600 60 Hz
Image to adjust [ 17]
800 x 600 60 Hz
Interlaced [ Off]
800 x 600 60 Hz
H.freq.crse [37.879] kHz
800 x 600 60 Hz
H.freq.fine [37.879] kHz
