14 tvONE
Note: some units do not have the [On] entry – this is only for units with a PIP button on the front, with
turns this entry On and Off. On these units, this feature is ‘Off’ by default, so that the full image size of
100% is used. Shrink level will need to be turned On before any change to this value has an effect.
This menu option determines the position of the shrunken image on the monitor screen. This will move
an image that is less than the full screen size left/right or up/down within the monitor’s available screen
space. It will not let you move the image off the screen, so certain values will appear to have no effect
(unless you use a very low Shrink value like 10%).
This item provides a simple way of changing the output screen aspect ratio, to suit the incoming video
signal and final output display size. Use the zoom/shrink functions for occasions when the aspect ratio is
an odd format.
See later section for further details on this item.
This is a feature only present in advanced units only. It greatly improves the method of frame-rate
conversion, by allowing the unit to merge frames together during the process.
When ‘Off’, the unit will use frame-repetition when converting 50Hz to 60Hz (i.e. it must duplicate every
5th frame), or frame-dropping when converting 60Hz to 50Hz (i.e. it must drop every 6
th
frame). When
‘On’, smooth blending is applied so that frames are not lost, but blended together at the appropriate
times.
The Flicker Reduction menu item will only appear if you have selected a low resolution interlaced output
such as PAL or NTSC. If you are using CV or YC outputs, this adjustment may be of interest, particularly
when you have line drawings or similar fine detail. You can choose from four possible Flicker Reduction
settings. You should use as little Flicker Reduction as possible because the Vertical detail will be softened
at the highest setting.
Flicker mode
Function
Off
Disables flicker reduction (sharpest mode).
Low
Suitable for most input sources.
Med.
Enough for most situations such as thin line drawings
High
Highest amount of flicker reduction. Will cause loss of vertical
detail in some images.
Adjust windows
H/V position % [100] [ 50]
Adjust windows
Aspect change [Normal]
Adjust windows
Aspect adjust [Simple]
Adjust windows
Temporal interp. [Off]
Adjust windows
Flicker Reduction [Low]
