12 tvONE
This menu item is only available when the Output resolution is set to PAL or NTSC. With this you can
change the output type to the PAL or NTSC standard with the further option of changing the output to the
additional PAL & NSTC standards such as PAL-M or PAL-N. SECAM is also available as an output on some
units, provided the ‘Output res’ is set to PAL / 50Hz.
This menu item is only available on certain units when the Output resolution is set to PAL or NTSC. With
this you can change the output filtering system to increase or decrease the image sharpness. In general,
high sharpness can result in increased color disturbance.
Sets the value of the fixed background color, which is present when PIP is used with no Lock source
background displayed. This menu item is only available for units with overlay, keying and fading abilities.
For certain units with HDMI and/or SDI-compatible inputs and outputs, the audio can be de-embedded
from the video signal and sent to a compatible output.
‘On’ enables this to happen, and allows the audio source to be selected. ‘WinA’ sets the audio source to
follow that of the main window’s video source.
The adjust windows menu
This menu group allows adjustment to be made to window specific parameters such as the window
source, its position, size and zoom level.
Window size adjustment can be performed in several different ways according to whether ‘Aspect adjust’
is set to Simple, Advanced or Pixel. The main part of this text assumes Simple mode – see later for a
detailed description of the other modes.
This menu item only appears on units with multiple windows or PIPs. It is used to select which one you
want to modify. Alternatively, use one of the dedicated buttons on the front panel to choose the window
to adjust.
The source display screen allows the input source for the currently selected window to be changed. The
top line of the display shows the detected characteristics of the signal. Valid Input sources match those
available on the front of the unit.
Adjust outputs
Stand. [NTSC-M/PAL-BDGHI]
Adjust outputs
Luma/chr BW [Med] / [Med]
Adjust outputs
Back Y/U/V [ 16] [128] [128]
Adjust outputs
Audio emb. [On] [DVI-U1]
Adjust windows
Window to adjust [A]
NTSC / 60Hz
Source [ YC1]
