The status message given in brackets has the following meaning:
Status
message
Description
Effect
No display
There is no display attached
(HOTPLUG is low).
Nothing will be output on the DVI connector.
Unavailable
The device attached is not capable of
supporting HDCP.
As the DVI output cannot be HDCP encrypted,
then a HDCP-encrypted source cannot be
selected for scaling.
Supported
The device attached is capable of
HDCP, but the output is not currently
encrypted.
As the DVI output is not HDCP encrypted, then a
HDCP-encrypted source cannot be selected for
scaling.
Active
The device attached is capable of
HDCP, and the output from the unit
is encrypted.
As the DVI output is HDCP encrypted, then a
HDCP-encrypted source can be selected for
scaling. Note that no other output connector
(SDI, CV, YC, YUV or RGBHV) will function – since
they are not encrypted.
Rep. supprt
The repeater unit (e.g. scaler)
attached is capable of HDCP, but the
output is not currently encrypted.
As the DVI output is not HDCP encrypted, then a
HDCP-encrypted source cannot be selected for
scaling.
Rep. active
The repeater unit (e.g. scaler)
attached is capable of HDCP, and the
output from the unit is encrypted.
As the DVI output is HDCP encrypted, then a
HDCP-encrypted source can be selected for
scaling. Note that no other output connector
(SDI, CV, YC, YUV or RGBHV) will function – since
they are not encrypted.
This menu may appear as either of the above – depending on whether the analog and digital outputs are
controlled separately.
This menu item allows you to select the type of signal output your unit will provide. Types of output vary
depending on the resolution selected and include various types of component signals YUV or tlYUV (tri-
level YUV) and the full range of RGB type signals RGBHV, RGBS and RGsB (Sync on green).
Note that this value is remembered for each resolution – so you can set 1024x768 60Hz to RGBHV and
1280x720 60Hz to tlYUV and both will be remembered separately. This value is not affected by a Factory
reset – but is reset by a firmware update.
This menu item is only available on certain units with an SDI output and when locking to a CV or YC input.
An internal de-jitter circuit ensures that the SDI output has a low jitter over the full 10Hz to 100kHz range,
even though the CV or YC input may have a high jitter. However, this is not always compatible with a
CV/YC output where the color sub-carrier should not be de-jittered and needs to follow a Lock source’s
input – hence it should be turned Off it the CV/YC outputs are going to be used.
Adjust outputs
Output type [RGBHV]
Adjust outputs
Anlog= [RGBHV] Dig= RGBHV
Adjust outputs
Optimize for SDI [On]
