8
5. Installation
Plan the layout path and deploy the UTP cable for
extension
1. Plan the path through which the CAT5 cable will be deployed
across the distance between the transmitter and the receiver. You
should choose the layout path not only based on shortest length
consideration, but also on least electromagnetic interference.
2. Lay out the UTP cable according to your planned path.
Configuring Transmitter Console
3. Connect one end of a CAT5 cable to the CAT5 extension port
(connector
9
) of the transmitter.
4. Connect the power adapter to the transmitter (connector
8
) to
power it up before connecting any computer or other cables to it.
5. Connect the transmitter to the TX PC, using the USB KVM combo
cable (connector
J
).
6. Connect a keyboard, mouse and monitor to the transmitter’s
console ports (connectors:
3
,
4
and
L
).
7. Power on the TX PC, and check if the keyboard, mouse and video
are working well, and then go on the following steps.
Configuring the Receiver Console
8. Connect the CAT5 cable from the transmitter to the CAT5
extension port (connector
9
) of the receiver.
9. Connect the power adapter to the receiver’s power jack (connector
8
) to power it up before connecting any devices to it.
10. Connect a keyboard, mouse, and monitor to the receiver’s
console ports (connector
3
,
4
and
L
).
11. Check if the keyboard, mouse and monitor are working well. At
this time, the video output of the RX unit might be blurry since it
hasn't been adjusted and optimized yet.
