12
4.3 Fit the Blade
4.3.1 Insert the locking pin (D).
4.3.2 Remove the blade sha bolt and outer blade
flange (E) using a 17mm socket or wrench.
4.3.3 Next, mount the blade (F) on the blade sha
and then attach the outer blade flange.
4.3.4 Tighten the bolt firmly using the 17mm socket
or wrench.
4.3.5 Mount the blade block guard (G) with vacuum
port. Tighten with a 10mm wrench until fully seated against the blade block. (If you are
replacing the blade, thoroughly clean the concrete from the sha, blade block and guard).
WARNING
Inspect the blade for damage, cracks, loss of segments, warping, overheating, excessive
wear or a damaged tri-arbor hole. If the blade shows any of these problems, safely
discard the blade.
Make sure the blade is marked with a maximum operating speed greater than 4450 rpm.
Inspect blade flanges for damage, excessive wear and cleanliness. The blade should fit
snugly on the clean, undamaged tri-arbor sha.
