WARNING
The patented skid plate is the most important part of the Early Entry Green Concrete
Saw system. If it is bent, twisted, or damaged, cuts may spall or cause ravelling. Store
skid plates carefully and install them properly. Install a new skid plate with each new
blade. Never reuse skid plates.
4.4 Installing a New Skid Plate
4.4.1 Hook the front of the skid plate (H) on the front blade block sha pin.
4.4.2 Connect the rear blade block sha (I) and the rear of the skid plate by installing the
locking pin (J).
4.4.3 Li the front and rear of the skid plate to ensure the blade slides freely through the skid
plate.
4.4.4 Ensure the lexan cover (K) moves freely up and down.
