49
16.3. TS-D1000-EX Extension Unit
Power Source 100 to 240 V AC, 50/60 Hz (use of the supplied AC adapter)
Power Consumption 25 W or less
Connection Terminal RJ45 connector ×2
LED Indicator Power indicator
Operating Temperature 0 to 40 ºC (32 to 104 ºF)
Operating Humidity 90%RH or less (no condensation)
Finish ABS resin, white (RAL 9003 equivalent)
Dimensions 124.3 (w) x 100.3 (h) x 35 (d) mm (4.89" x 3.95" x 1.38")
Weight 150 g (0.33 lb) (unit only)
Note: The design and specications are subject to change without notice for improvement.
• Accessory
AC adapter (Cord length: 1.8 m or 5.91 ft DC cord, and 2 m or 6.56 ft detachable AC cord) ...... 1
16.4. TS-D1000-CU Chairman Unit
Power Source 24 V DC
( supplied from the optional TS-D1100-MU Master control unit, optional TS-
D1000-SU Sub control units, or optional TS-D1000-EX Extension units)
Power Consumption 1.5 W or less
Signal to Noise Ratio 65 dB or more (A-weighted)
Input Microphone terminal: XLR-3-31 type
Output Monitor speaker: 8 Ω, 0.4 W
Earphone: ø3.5 mm mini Jack (3P: monaural) x 2
Speaker Output 75 dB SPL
Connecting Terminal RJ45 connector x 2
LED Indicator Power indicator, Speech indicator
Function Speech function, Priority speech function, Earphone volume control x 2
Operating Temperature 0 to 40 °C (32 to 104 °F)
Operating Humidity 90%RH or less (no condensation)
Finish Case: ABS resin, black, mat nish, paint
Speaker net: Steel plate, black, mat nish, paint
Dimensions 208.9 (w) x 71.3 (h) x 160.5 (d) mm (8.22" x 2.81" x 6.32")
Weight 880 g (1.94 lb)
Note: The design and specications are subject to change without notice for improvement.
