48
*
1
0 dB = 1 V
*
2
Cable length can be extended to a maximum of 100 m (328.08 ft) with the use of the Extension unit.
*
3
A USB 2.0 – Compatible FAT32 – formatted ash memory device of up 32 GB in capacity can be used. There
may be cases in which a USB ash drive cannot be used with the TS-D1100-MU, depending on the drive’s
attributes or recording conditions.
Note: The design and specications are subject to change without notice for improvement.
• Accessories
AC adapter (Cord length: 1.8 m or 5.91 ft DC cord, and 2 m or 6.56 ft detachable AC cord) ...... 1
USB cable (Cable length: 3 m or 9.84 ft) ..................................................................................... 1
• Optional product
Rack mounting bracket: MB-TS920
16.2. TS-D1000-SU Sub Control Unit
Power Source 100 to 240 V AC, 50/60 Hz (use of the supplied AC adapter)
Power Consumption 80 W or less
Number of Connectable
Conference Units
48 units
Conference units Terminal RJ45 connector ×3
Sub Control Units Terminal RJ45 connector ×2
Maximum Cable Distance 50 m
or 164.04 ft ( between this unit and Conference unit at the end of daisy
chain)*
LED Indicator Power indicator
Operating Temperature 0 to 40 ºC (32 to 104 ºF)
Operating Humidity 90%RH or less (no condensation)
Finish Panel: Aluminum, black, 30% glossy, paint
Case: Surface-treated steel plate, black, 30% glossy, paint
Dimensions 210 (w) x 45.8 (h) x 294.8 (d) mm (8.27" x 1.8" x 11.61")
Weight 1.6 kg (3.53 lb)
* Cable length can be extended to a maximum of 100 m (328.08 ft) with the use of the Extension unit.
Note: The design and specications are subject to change without notice for improvement.
• Accessories
AC adapter (Cord length: 1.8 m or 5.91 ft DC cord, and 2 m or 6.56 ft detachable AC cord) ...... 1
Connection cable (Cat5e STP, 1 m or 3.28 ft) .............................................................................. 1
• Optional products
Rack mounting bracket: MB-15B-BK (for rack mounting one TS-D1000-SU unit)
Rack mounting bracket: MB-15B-J (for rack mounting two TS-D1000-SU units)
Operating Humidity 90%RH or less (no condensation)
Finish Panel: Surface-treated steel plate, black, 30% glossy, paint
Dimensions 361 (w) x 100.4 (h) x 184.2 (d) mm (14.21" x 3.95" x 7.25")
Weight 2.2 kg (4.85 lb)
