47
16. SPECIFICATIONS
16.1. TS-D1100-MU Master Control Unit
Power Source 100 to 240 V AC, 50/60 Hz (use of the supplied AC adapter)
Power Consumption 60 W or less
Audio Transmission System Time division multiplexing (TDM), 10 channels
16-bit, PCM, 32 kHz sampling frequency
Frequency Response 100 Hz – 13 kHz
Total Harmonic Distortion 0.5% or less
Signal to Noise Ratio 80 dB or more (A-weighted )
MIC Input –54 dB *
1
, 600 Ω, unbalance, ø6.3 mm phone jack (2P)
Output LINE: –10 dB *
1
, 10 kΩ, unbalance, ø6.3 mm phone jack (2P)
REC: –10 dB *
1
, 10 kΩ, unbalance, RCA pin jack, monaural
HEADPHONES: ø3.5 mm mini jack, monaural
USB Audio Input/Output USB 2.0, type-B port
EQ Insert Input/Output Terminal –10 dB *
1
, 10 kΩ, unbalance, RCA pin jack
Video Conference System
Input/Output Terminal
–10 dB *
1
, 10 kΩ, unbalance, RCA pin jack
Number of Connectable
Conference Units
32 units
Number of Connectable
Sub Control Units
5 units
Maximum Cable Distance 50 m or 164.04 ft ( between Master control unit and terminal Conference
unit at end of daisy chain)*
2
1 m or 3.28 ft ( between Master control unit and Sub control units, use the
cable supplied with the Sub control unit.)
Maximum Number of Open
Microphones
2 chairman units, 8 delegate and microphone units
Conference
Units Terminal
RJ45 connector x 2
Sub Control Units Terminal RJ45 connector
LED Indicator Power indicator, Conference mode indicator,
Max. open mic No. indicator, Mic auto-o indicator,
Monitor volume indicator, Connection test indicator, External control
indicator, Setting lock indicator,
Recording status indicator, Access indicator,
USB memory device indicator, Internal memory indicator,
USB memory device remaining capacity warning indicator,
Internal memory remaining capacity warning indicator,
LINK/ACT indicator, 10 BASE-T/100BASE-TX indicator,
Function Key Conference mode selector key: Standard/Override/Voice activation/
Chairman Only
Max. open mic No. setting key: 1/2/8
Mic auto-o setting key: ON/OFF
Monitor volume control keys: –, +
Setting lock key: ON/OFF
Headphone volume control keys: –, +
Operation Key Connection test key, Recording STOP key, Recording START key
Recording Ports USB-A
Recording Function Recordings can be made to a USB memory device *
3
or the internal
memory.
Recording format: MP3 (MPEG-1 Audio Layer-3), monaural,
Sampling frequency: 32 kHz, Bit rate: 128 kbps
Network I/F 10BASE-T/100BASE-TX (Auto-negotiation)
Network Protocol TCP, HTTP, DHCP, ARP (APIPA), UDP (mDNS), UPnP
Network Connector RJ45 connector
Operating Temperature 0 to 40 °C (32 to 104 °F)
