50
16.5. TS-D1000-DU Delegate Unit
Power Source 24 V DC
( supplied from the optional TS-D1100-MU Master control unit, optional TS-
D1000-SU Sub control units, or optional TS-D1000-EX Extension units)
Power Consumption 1.5 W or less
Signal to Noise Ratio 65 dB or more (A-weighted)
Input Microphone terminal: XLR-3-31 type
Output Monitor speaker: 8 Ω, 0.4 W
Earphone: ø3.5 mm mini Jack (3P: monaural) x 2
Speaker Output 75 dB SPL
Connecting Terminal RJ45 connector x 2
LED Indicator Power indicator, Speech indicator
Function Speech function, Earphone volume control x 2
Operating Temperature 0 to 40 °C (32 to 104 °F)
Operating Humidity 90%RH or less (no condensation)
Finish Case: ABS resin, black, mat nish, paint
Speaker net: Steel plate, black, mat nish, paint
Dimensions 208.9 (w) x 71.3 (h) x 160.5 (d) mm (8.22" x 2.81" x 6.32")
Weight 875 g (1.93 lb)
Note: The design and specications are subject to change without notice for improvement.
16.6. TS-D1000-M1 Standard Microphone and TS-D1000-M2 Long Microphone
Model No. TS-D1000-M1 TS-D1000-M2
Type Electret condenser microphone
Directivity Unidirectional
Rated Impedance 1.4 kΩ
Rated Sensitivity –37 dB (1 kHz, 0 dB = 1 V/Pa)
LED Indicator Indicator (ring type), Red
Frequency Response 100 Hz to 13 kHz
Output Connector Equivalent to XLR-3-12C
Operating Temperature 0 to 40 °C (32 to 104 ºF)
Operating Humidity 90%RH or less (no condensation)
Finish Shaft: Brass, black
Other: ABS resin, black
Length 518 mm (1.7 ft) 668 mm (2.19 ft)
Weight 110 g (0.24 lb) 125 g (0.28 lb)
Applicable Unit Chairman unit: TS-D1000-CU, Delegate unit: TS-D1000-DU
Note: The design and specications are subject to change without notice for improvement.
