Programming the Robots

• The “Opening” program segment (K) runs once at the

beginning when the Go buon is pressed.

• When an object is detected between 0 and 30, the blue

0-30 segment (L) runs.

• When an object is detected between 30 and 50, the

green 31-50 segment (M) runs.

• When an object is detected between 50 and 100, the

purple >51 segment (N) runs.

You can slide the range markers to change the distance

ranges. You can also increase the number of distance

range segments by pressing the add range marker buon

(O). You can delete a segment with the delete buon (P).

Range markers must be a minimum of 5 distance units

apart. You cannot add a new range marker if there is

another marker at 90 or higher.

WRITING A PROGRAM

1. Now you are ready to write your ﬁrst program. Click

the gear buon (A) to enter the programming mode.

Choose a blank program (Program 8 starts out blank).

2. The programming screen appears.

3. Press the plus sign “+” buon (B) in one of the program

segments to add a command.

4. The commands menu (C) pops up. You can select

between three types of commands:

• Choose Motors to add motor commands.

• Choose Notes to add sound commands.

• Choose Rest to add a pause command.

Or press the red X buon to exit the commands menu.

Continued on next page >>>

TROUBLESHOOTING THE SENSOR

CONNECTION

If the sensor connection isn’t working:

››› Disconnect and then reestablish the

Bluetooth connection.

››› Make sure the sensor cable is securely

plugged into the baery box.

››› Exit the program you are in and relaunch it.
