4. Take the silicone hose and measure a piece

that is 15 cm long. Cut this piece off and put

it in the green roof plastic tray. You will need

it there later.

5. To assemble the climate control module,

remove the top cover from the wall-

mounted hose holder. Now press the

remaining silicone hose into the curved

recesses. There should be about 15 cm of

hose sticking out on each side. Replace

the top cover.

6. Place the climate control module into the

back wall of the house from the outside.

The top cover should be facing the inside

of the house. Before pushing the module

all the way in, thread the two ends of the

hose through the two holes in the back

wall from the inside to the outside.

Attach the water pump to the end of the

hose that is near the bottom left corner

of the house.

7. Stick the thermometer sticker inside the

house on the top cover of the climate control

module. Make sure it isn’t upside down!

8. Use tape to attach the LED set as follows:

Attach the circuit board with the light sensor

to the left inner wall a little below the top

edge. Don’t stick it too close to the top edge

of the wall! Place the black power cable in

the notch in the top edge of the left wall, so it

can reach the battery station. Line up the

two cables of the LEDs along the roof beam.

The LED with the shorter cable will dangle

and become the lamp. Put the LED on the

longer cable through the hole in the top of

the screen frame. Then secure the cables to

the roof beam with adhesive tape.

ASSEMBLY
