Insert tabs

E here

Assembly

Assembling the

extension

You will need

– Model house punch boards 1, 2, and 3

– Battery station

– Solar cell with cable and adhesive

– Green roof plastic tray

– 15 cm silicone hose

– Cotton pad

– Transparent window film

– Measuring cup

– Sticker sheet

– Tape

Here’s how

1. Press the parts for the extension out of the

punch boards. Slot panels A and B into each

other at the corners. Make sure that the

printed sides face outwards.

2. Then insert the floor for the battery station

(C), with the gray side face up.

3. Then place the balcony floor (D) with the

side face up. Slot panel E into panel A at the

corners, and make sure the tabs for both

horizontal panels are in the slots. Insert

tabs E securely into the slots on the floor.

4. Slide the extension into the opening in

the left side of the main house so that it

sits securely.

5. Insert the battery station from inside the

house with the ports facing the opening in the

rear wall of the extension and slide it so that

it sits securely between the tabs in the floor.

6. Glue the transparent window film to the inside

of the front of the house so that all windows

are covered with the film.

ASSEMBLY
