6
ELITE
User Manual
©2025 AMETEK SurgeX | B01-00014 (REV A) Technical Support: 800-645-9721 | surgex.com
2.11.4 Front Key Switch
Front key Switch (M): The front key switch is used to turn the unit on and off. Use the provided
key, which comes in the box, to turn the switch to the right (clockwise) to switch the unit on,
and to the left (anticlockwise) to switch it off. The key can be removed from the unit in both
the on and off positions. Make sure to store the key safely in a secure place when not in use
to prevent loss or damage. The front key switch shall be only for the SX-AEP-159 and SX-
AEP-209 models.
3. Rack Installation
Axess ELITE+ is designed to be installed horizontally in the equipment rack. The supplied nuts, bolts and
washers must be used to mount the Axess ELITE+ to the rack through the mounting holes (A) following the
appropriate local regulations and requirements.
Inventory
SI. No Items Qty
1 Axess ELITE+ Unit 1
2 Ear Mount Bracket 2
3 Flat Head Screws 8
4 Cage Nut 4
5 Pan Head Screws 4
DANGER
HAZARD OF ELECTICAL SHOCK, EXPLOSION, OR ARC FLASH
• This Unit is intended to use indoor only.
• Do not install this Unit where excessive moisture or heat is present.
• Never install any wiring, equipment, or Units during a lightning storm.
• Plug this Unit into a three-wire, grounded power outlet only. The power
outlet must be connected to appropriate branch circuit/mains protection
(fuse or circuit breaker). Connection to other type of power outlet may result
in a shock hazard.
• Install the unit in such a way that the Wall socket-outlet should be readily
accessible.
• Use only the supplied brackets for mounting and use only the supplied
hardware to attach the mounting brackets
• Do not use extension cords or adapters with this Unit
• If a socket-outlet is not accessible to the equipment, a socket-outlet shall be
installed.
• Do not work alone under hazardous conditions.
• Check that the power cord, plug, and socket are in good condition.
• Disconnect the Unit from the power outlet before you install or connect
equipment to reduce the risk of electric shock when you cannot verify
grounding. Reconnect the Surge Unit to the power outlet only after you
make all connections
• UnitinstallationinstructionsthatrequirevericationoftheProtective
earthing connection of the socket-outlet by a Skilled person.
• This equipment is not suitable for use in locations where children are likely
to be present.
• Use a protective earth connector with equipment. This type of connector
carries the leakage current from the load devices (computer equipment).
• Do not exceed a total leakage current of 3.5 mA
• Do not handle any kind of metallic connector before the power has been
removed
• Use one hand, whenever possible, to connect or disconnect signal cables to
avoid a possible shock from touching two surfaces with different grounds.
• This unit does not have any user-serviceable parts. Repairs are to be
performed only by factory-trained service personnel.
• The Unit is intended to be installed and operated by a skilled person in as
controlled location with restricted access.
• The ambient operating temperature of a closed or multi-unit rack
environment may be greater than the ambient temperature of the room.
Ensure the ambient operating temperature of your rack environment does
not exceed the rated ambient operating temperature for the device.
• Ensure the Unit is mounted securely and evenly.
• To avoid possible electrical shock and equipment damage, Use only the
supplied hardware.
Failure to follow these instructions will result in death or serious injury
