5
ELITE
User Manual
©2025 AMETEK SurgeX | B01-00014 (REV A) Technical Support: 800-645-9721 | surgex.com
2.9 Wiring details:
Contact Closure
CC1 CC2 +5V SDA SCK GND NO NC COM NO NC COM
Temperature/Humidity Auxiliary Relay A Auxiliary Relay B
2.10 LED Indicators:
The receptacles have individual power indicator LEDs (F). This are paralleled in the control interface.
In addition, the unit has an LED indicating power (G), Shut down is indicated by (L) and Self -Test is
indicated by (C).
Mains Shutdown Self-Test
A B 1 2 3 4 5 6 7 8 9 10 11
LED INDICATORS
Indicator Colour Description
Mains Red Whenilluminated,theAxessEliteisconnectedtoalivewallorooroutlet.
Shutdown Amber
When illuminated, the Axess Elite is in shutdown mode due to out of range line voltage,
current, or temperature.
Self-Test Green When illuminated, the surge suppression circuitry is functioning correctly.
Aux Relays Green When illuminated, the corresponding auxiliary relay is latched.
Outlets Green When illuminated, the corresponding AC outlet is on.
2.11 Buttons
2.11.1 Resettable Fuse
The resettable fuse (H) is used to reset the Axess ELITE+ in case the fuse tripped. This is a
single push button to the bottom left of the Ethernet RJ-45 jack. Also, there is a reset switch
for hardware and another for software.
2.11.2 Hardware Reset
Hardware Reset (I): The Hardware Reset button performs a hard reboot of the processor.
This hard reboot will immediately switch controlled outlets off, removing power to connected
equipment on all outputs.
2.11.3 Software Reset
Software Reset (J): The Software Reset button is a multi-functional control depending on
length of press. If the button is held for longer than 10 seconds, the unit resets itself to factory
defaults, and all custom congurations are erased. If the button is held for less than 10
seconds, the unit will perform a software reset that will not reset any data, or power cycle the
connected equipment.
