7
ELITE
User Manual
©2025 AMETEK SurgeX | B01-00014 (REV A) Technical Support: 800-645-9721 | surgex.com
3.1 Rack Mounting Options
Option 1: Mounting Ear Mount Bracket at Front
Secure Ear Mount Brackets to the Unit using eight Flat head screws
Option 2: Mounting Ear Mount Bracket at Rear
Secure Ear Mount Brackets to the Unit using eight Flat head screws
Option 3: Mounting Ear Mount Bracket at the Center
Secure Ear Mount Brackets to the Unit using eight Flat head screws
Option 4: Mounting Ear Mount Bracket at the Center
Secure Ear Mount Brackets to the Unit using eight Flat head screws
3.2 Unit Installation into the Rack
Horizontal Mounting: Mount Unit on 19” rack holes provided in the channel and secure the Unit using
four Pan head screws.
