Headers and Connections
For information about the headers of the X14SBH-AP motherboard, refer to the following
content.
BMC LAN/USB/VGA Connector
A low-profile SlimSAS I/O x8 connector, located at JIO1 on the X14SBH-AP motherboard,
provides dedicated BMC LAN/USB/VGA support for rear access.
Chassis Intrusion
A Chassis Intrusion header is located at JL1 on the X14SBH-AP motherboard. Attach the
appropriate cable from the chassis to inform you when the chassis is opened.
For a detailed diagram of the X14SBH- AP motherboard, see the layout under "Quick
Reference" on page 12.
Chassis Intrusion
Pin Definitions: Two Total
Pin# Definition
1 Intrusion Input
2 GND
External BMC I²C Headers for Backplane
Two System Management Bus 4-pin headers for the BMC are located at JBPNI²C1 and
JBPNI²C2 on the X14SBH-AP motherboard. Connect the appropriate cable here to connect the
BMC to the backplane.
For a detailed diagram of the X14SBH- AP motherboard, see the layout under "Quick
Reference" on page 12.
External I²C Header
Pin Definitions: Four Total
Pin# Definition
1 Data
2 GND
3 Clock
4 +3.3 V
52
X14SBH-AP: Component Installation
