2.6 Connections, Jumpers, and LEDs
Refer to the following sections for information about connections, jumpers, and LEDs for the
X14SBH-AP motherboard.
Power Supply and Power Connections
For information about the power connections of the X14SBH-AP motherboard, refer to the
following content.
Power Supply
As with all computer products, a stable power source is necessary for proper and reliable
operation. It is even more important for processors that have high CPU clock rates where noisy
power transmission is present.
Two power supply connectors, located at PSU1/PSU2, provide main power to your hyper
server, and 10 8-pin power connectors (JPWR1–JPWR10) are used for +12 V devices.
Note: Refer to the table below for the power supplies that support the main power supply
units (PSU1/PSU2) in the Supermicro hyper servers. For detailed power supply support for
your particular server, refer to your hyper server user manual.
Power Supplies for PSU1/PSU2
PWS-1K24A-1R PWS-1K31D-1R
PWS-1K63A-1R PWS-2K07A-1R
PWS-2K07A-27
Power Connectors
JPW1–JPW10 are the 8-pin power connectors located on the X14SBH-AP motherboard. In
addition, there are two power supply units for system use located at PSU1 and PSU2.
8-pin Power Connectors for Backplane/GPU Devices
Pin Definitions: Eight Total
Pin# Definition
1–4 GND
5–8 +12 V (12 V Power)
51
X14SBH-AP: Component Installation
