Note: For detailed instructions on how to configure Network Interface Card (NIC) settings,
refer to the Network Interface Card Configuration User's Guide posted on the web page
under the link: https://www.supermicro.com/support/manuals.
For a detailed diagram of the X14DBT-FAP/-FLAP motherboard, see the layout under "Quick
Reference" on page 12.
PCIe 5.0 x16 Expansion Slot
There is a PCIe 5.0 x16 expansion slot for AOC located at JPCIE4 (P1_PE0 0-15) on the
X14DBT-FAP/-FLAP motherboard. This expansion slot supports PCIe 5.0 x16 devices.
For a detailed diagram of the X14DBT-FAP/-FLAP motherboard, see the layout under "Quick
Reference" on page 12.
I/O Module Connector
There is an I/O Module Connector on the motherboard at JRIO1. Connect this to provide a
2x10 connection Dedicated BMC LAN access, UID, and BMC LED to the motherboard.
For a detailed diagram of the X14DBT-FAP/-FLAP motherboard, see the layout under "Quick
Reference" on page 12.
TPM/Port 80 Header
The JTPM1 header on the X14DBT-FAP/-FLAP motherboard is used to connect a Trusted
Platform Module (TPM)/Port 80, which is available from Supermicro (optional). A TPM/Port 80
connector is a security device that supports encryption and authentication in hard drives. It
allows the motherboard to deny access if the TPM associated with the hard drive is not installed
in the system. Information on the TPM is available at the following page:
https://www.supermicro.com/manuals/other/AOM-TPM-9670V_9670H__X12_H12.pdf
For a detailed diagram of the X14DBT-FAP/-FLAP motherboard, see the layout under "Quick
Reference" on page 12.
Trusted Platform Module Header
Pin Definitions: 10 Total
Pin# Definition Pin# Definition
1 +3.3 V 2 SPI_CS#
3 RESET# 4 SPI_MISO
5 SPI_CLK 6 Ground
7 SPI_MOSI 8 No Connection
9 +1.8 V Standby 10 SPI_IRQ#
52
X14DBT-FAP/-FLAP: Component Installation
