Chapter 2 Installation and Setup

2.6 Storage Drives

The blade has two or three 2.5" hot-swap storage drive bays. The drives are mounted in drive

carriers that simplify their removal from the chassis. These carriers also help promote proper

airow. Even carriers without drives must remain in the chassis for proper airow.

The blade can be purchased with drives installed or without drives installed.

For VROC congurations, refer to the VROC appendix in this manual.

Note: Enterprise level storage drives are recommended for use in Supermicro systems. For

information on recommended drives, visit the Supermicro website.

Drive Carrier Indicators

Each drive carrier has two LED indicators: an activity indicator and a status indicator. For

RAID congurations using a controller, the meaning of the status indicator is described in

the table below. For OS RAID or non-RAID congurations, some LED indications are not

supported, such as hot spare.

Drive Carrier LED Indicators

Color Blinking Pattern Behavior for Device

Activity

LED

Blue Solid On SAS/NVMe drive installed

Blue Blinking I/O activity

Status

LED

Red Solid On Failure of drive with RSTe support

Red Blinking at 1 Hz Rebuilding drive with RSTe support

Red Blinking with two blinks

and one stop at 1 Hz

Hot spare for drive with RSTe support

(not supported in VMD mode)

Red On for ve seconds,

then o󰀨

Power on for drive with RSTe support

Red Blinking at 4 Hz Identify drive with RSTe support

Green Solid On Safe to remove NVMe device

(not supported in VMD mode)

Amber Blinking at 1 Hz Attention state—do not remove NVMe device

(not supported in VMD mode)
