Fan Header
Pin Definitions
Pin# Definition
1 Ground (Black)
2 +12 V (Red)
3 Tachometer (Yellow)
4 PWM control (Blue)
5 12 V
6 Ground
TPM/Port 80 Header
The JTPM1 header on the H14DSG-OD motherboard is used to connect a Trusted Platform
Module (TPM)/Port 80, which is available from Supermicro (optional). A TPM/Port 80 connector
is a security device that supports encryption and authentication in hard drives. It allows the
motherboard to deny access if the TPM associated with the hard drive is not installed in the
system. Information on the TPM is available at the following page:
https://www.supermicro.com/manuals/other/AOM-TPM-9670V_9670H__X12_H12.pdf
For a detailed diagram of the H14DSG- OD motherboard, see the layout under "Quick
Reference" on page 12.
Trusted Platform Module Header
Pin Definitions: 10 Total
Pin# Definition Pin# Definition
1 +3.3 V 2 SPI_CS#
3 RESET# 4 SPI_MISO
5 SPI_CLK 6 Ground
7 SPI_MOSI 8 No Connection
9 3V3_AUX 10 SPI_IRQ#
NC-SI Connection
The Network Controller Sideband Interface (NC-SI) connection is located at JNCSIBF3. This
connection is used to connect a Network Interface Card (NIC) to the motherboard to allow the
onboard Baseboard Management Controller (BMC) to communicate with a network.
45
H14DSG-OD: Component Installation
