Note: For detailed instructions on how to configure Network Interface Card (NIC) settings,
refer to the Network Interface Card Configuration User's Guide posted on the web page
under the link: https://www.supermicro.com/support/manuals.
For a detailed diagram of the H14DSG- OD motherboard, see the layout under "Quick
Reference" on page 12.
Fan Board I
2
C Header
An I
2
C fan header for the fan board is located at JP3. Fan speed control for this fan is
supported by Thermal Management via the BMC 2.0 interface. See the table below for pin
definitions.
Fan Board I
2
C Header
Pin Definitions
Pin# Definition
1 SDA
2 Ground
3 SCL
4 P3V3_AUX
NVMe / SATA I2C Header
The NVMe / SATA SMBus (I2C) header (JRSI2C1) provides hot-plug support via a dedicated
SMBus interface. This feature is only available for a Supermicro complete system with an
Supermicro-proprietary NVMe / SATA add-on card and a proper cable installed. See the table
below for pin definitions.
NVMe / SATA I2C Header
Pin Definitions
Pin# Definition
1 SDA
2 Ground
3 SCL
4 P3V3_AUX
46
H14DSG-OD: Component Installation
