14.06.2021
Description of the parameter
Value of the
parameter
Product name
ELECTRIC
CENTRIFUGE
Model SBS-LZ-300D
Supply voltage [V~]/
Frequency [Hz]
230/50
Rated power [W]. 45
Speed [RPM] 12000
Maximum number of test
tubes
48
Test tube capacity 0,2/0,5/1,5/2 ml
Maximum relative centrifugal
force (RCF)
9660x g
Time range 1 s – 99 min
Ambient temperature [°C]. 5 – 40
Safety class I
IP code IPX0
Dimensions [Width x Depth x
Height; mm]
270x250x120
Weight [kg] 1,6
Wear protective gloves.
Wear a protective apron.
CAUTION! Warning of electric shock!
CAUTION! Spinning elements!
TECHNICAL DATA
USER MANUAL
The product satises the relevant safety
standards.
Read instructions before use.
The product must be recycled.
WARNING! or CAUTION! or REMEMBER!
Applicable to the given situation. (general
warning sign).
The terms „device“ or „product“ are used in the warnings
and instructions to refer to ELECTRIC CENTRIFUGE.
2.1. ELECTRICAL SAFETY
a) The plug must t the socket. Do not modify the
plug in any way. Using original plugs and matching
sockets reduces the risk of electric shock.
b) Avoid touching earthed elements such as pipes,
heaters, boilers and refrigerators. There is an
increased risk of electric shock if the earthed device is
exposed to rain, comes into direct contact with a wet
surface or is operating in a damp environment. Water
getting into the device increases the risk of damage
to the device and of electric shock.
c) Do not touch the device with wet or damp hands.
d) Use the cable only for its designated use. Never use it
to carry the device or to pull the plug out of a socket.
Keep the cable away from heat sources, oil, sharp
edges or moving parts. Damaged or tangled cables
increase the risk of electric shock.
e) If using the device in a damp environment cannot be
avoided, a residual current device (RCD) should be
applied. The use of an RCD reduces the risk of electric
shock.
f) Do not use the device if the power cord is damaged
or shows obvious signs of wear. A damaged power
cord should be replaced by a qualied electrician or
the manufacturer‘s service centre.
g) To avoid electric shock, do not immerse the cord,
plug or device in water or other liquids. Do not use
the device on wet surfaces.
h) ATTENTION! DANGER TO LIFE! While cleaning, never
immerse the device in water or other liquids.
i) Do not use in very humid environments or in the
direct vicinity of water tanks.
j) Prevent the device from getting wet. Risk of electric
shock!
2.2. SAFETY IN THE WORKPLACE
a) Make sure the workplace is clean and well lit. A
messy or poorly lit workplace may lead to accidents.
Try to think ahead, observe what is going on and use
common sense when working with the device.
b) If you discover damage or irregular operation,
immediately switch the device o and report it to a
supervisor without delay.
PLEASE NOTE! Drawings in this manual are for
illustration purposes only and in some details may
dier from the actual product.
The original operation manual is in German. Other
language versions are translations from German.
2. USAGE SAFETY
ATTENTION! Read all safety warnings and all
instructions. Failure to follow the warnings and
instructions may result in an electric shock, re and/
or serious injury or even death.
1. GENERAL DESCRIPTION
The user manual is designed to assist in the safe and
trouble-free use of the device. The product is designed
and manufactured in accordance with strict technical
guidelines, using state-of-the-art technologies and
components. Additionally, it is produced in compliance
with the most stringent quality standards.
DO NOT USE THE DEVICE UNLESS YOU HAVE
THOROUGHLY READ AND UNDERSTOOD THIS
USER MANUAL.
To increase the product life of the device and to ensure
trouble-free operation, use it in accordance with this user
manual and regularly perform maintenance tasks. The
technical data and specications in this user manual are
up to date. The manufacturer reserves the right to make
changes associated with quality improvement. The device
is designed to reduce noise emission risks to a minimum,
taking into account technological progress and noise
reduction opportunities.
LEGEND
Wear protective goggles.
Wear protective gloves.
2.3. PERSONAL SAFETY
a) Do not use the device when tired, ill or under the
inuence of alcohol, narcotics or medication which
can signicantly impair the ability to operate the
device.
b) The device is not designed to be handled by persons
(including children) with limited mental and sensory
functions or persons lacking relevant experience and/
or knowledge unless they are supervised by a person
responsible for their safety or they have received
instruction on how to operate the device.
c) The device can be handled only by physically t
persons who are capable of handling it, properly
trained, familiar with this manual and trained within
the scope of occupational health and safety.
d) When working with the device, use common sense
and stay alert. Temporary loss of concentration while
using the device may lead to serious injuries.
e) Use personal protective equipment as required
for working with the device, specied in section 1
(Legend). The use of correct and approved personal
protective equipment reduces the risk of injury.
f) To prevent the device from accidentally switching on,
make sure the switch is on the OFF position before
connecting to a power source.
g) Do not wear loose clothing or jewellery. Keep hair,
clothes and gloves away from moving parts. Loose
clothing, jewellery or long hair may get caught in
moving parts.
h) The device is not a toy. Children must be supervised to
ensure that they do not play with the device.
i) Do not put your hands or other items inside the
device while it is in use!
2.4. SAFE DEVICE USE
a) Do not use the device if the ON/OFF switch does not
function properly (does not switch the device on and
o). Devices which cannot be switched on and o
using the ON/OFF switch are hazardous, should not
be operated and must be repaired.
b) Disconnect the device from the power supply
before commencement of adjustment, cleaning and
maintenance. Such a preventive measure reduces the
risk of accidental activation.
c) When not in use, store in a safe place, away from
children and people not familiar with the device who
have not read the user manual. The device may pose a
hazard in the hands of inexperienced users.
d) Keep the device in perfect technical condition. Before
each use check for general damage and especially
check for cracked parts or elements and for any other
conditions which may impact the safe operation of the
device. If damage is discovered, hand over the device
for repair before use.
e) Keep the device out of the reach of children.
f) Device repair or maintenance should be carried out by
qualied persons, only using original spare parts. This
will ensure safe use.
g) To ensure the operational integrity of the device, do
not remove factory-tted guards and do not loosen
any screws.
h) Avoid situations where the device stops working
during use due to excessive loading. This may result in
overheating of the drive elements and damage to the
device.
i) Do not touch articulated parts or accessories unless
the device has been disconnected from the power
source.
j) Do not move, adjust or rotate the device in the course
of work.
k) Do not leave this appliance unattended while it is in
use.
l) Clean the device regularly to prevent stubborn grime
from accumulating.
m) The device is not a toy. Cleaning and maintenance
may not be carried out by children without supervision
by an adult person.
n) It is forbidden to interfere with the structure of
the device in order to change its parameters or
construction.
o) Keep the device away from sources of re and heat.
p) Do not overload the device.
q) Do not cover the ventilation openings!
r) A ammable, explosive or corrosive test sample may
damage or shorten the life of the device. Any damage
caused by the above-mentioned type test samples are
not covered by the warranty.
s) The maximum rotor speed must not be exceeded.
t) The condition of the rotor should be frequently
checked (for cracks, corrosion, damaged seals,
scratches, etc.). Do not use the device if the rotor is
not in good technical condition.
u) You must never open the device cover while it is
working! The lid can be opened with the device
switched o and the rotor at a standstill.
v) Uneven alignment or use of damaged test tubes can
cause severe vibrations and damage the device.
c) If there are any doubts as to the correct operation
of the device, contact the manufacturer‘s support
service.
d) Only the manufacturer‘s service point may repair the
device. Do not attempt any repairs independently!
e) In case of re, use a powder or carbon dioxide
(CO
2
) re extinguisher (one intended for use on live
electrical devices) to put it out.
f) Children or unauthorised persons are forbidden to
enter a work station. (A distraction may result in loss
of control over the device).
g) Regularly inspect the condition of the safety labels. If
the labels are illegible, they must be replaced.
h) Please keep this manual available for future
reference. If this device is passed on to a third party,
the manual must be passed on with it.
i) Keep packaging elements and small assembly parts
in a place not available to children.
j) Keep the device away from children and animals.
REMEMBER! When using the device, protect
children and other bystanders.
ATTENTION! Despite the safe design of the device
and its protective features, and despite the use of
additional elements protecting the operator, there is
still a slight risk of accident or injury when using the
device. Stay alert and use common sense when using
the device.
EN EN
