GX2200

External GPS Connections (4800 baud or 38400 baud)

The GX2200canselecttheNMEAbaudratebetween“4800bps”and“38400

bps”.Refertosection“10.6 NMEA DATA IN/OUT”forselection.

NMEAInput(GPSInformation)

• GX2200canreadNMEA-0183version2.0orhigher.

• TheNMEA0183inputsentencesareGLL,GGA,RMC,GNS,GSA,and

GSV(RMCsentenceisrecommended).

• If4800baud(default)isselected:

a. Ifthereisaselectionfor“PARITY”select“NONE”.

b. TheBlueandGreenwiresofinputareat4800baud.

• If38400baudisselected:

TheBlueandGreenwiresofinputareat38400baud.

NMEAOutput(DSCandGPSinformation)

• TheNMEA0183outputsentencesareDSCandDSE.

• If4800baud(default)isselected:

a. TheGrayandBrownwiresoutputDSCandDSEsentences.

b. TheYellowandWhitewiresofoutputAISVDMsentenceat

38400baud.

• If38400baudisselected:

a. TheGrayandBrownwires ofoutput are at38400 baud and

includesbothDSC(DSC,DSE)andAIS(VDM)sentences.

b. TheYellowandWhitewiresalwaysoutputAISsentencesat

38400baud.

• GSA,GSV,GLL,GGA,andRMCsentencescanbeoutputinthe

GX2200bysettingthroughtheGPSsetupmenu(refertosection“15.11

NMEA OUTPUT”).
