Page 32
Water Hazard
1. Press and hold the [MENU/SET] key.
2. Press the [▲] or [▼] key to select “CONFIG”, then press the [SELECT]
soft key.
3. Select “STROBE LED” with the [▲] or [▼] key, then press the [SELECT]
soft key.
4. Select “WATER HAZARD” with the [▲] or [▼] key, then press the [SE-
LECT] soft key.
5. Press the [▲] or [▼] key to select the de-
sired setting. You can select one from “OFF”,
“ON”, or “ON/PWR ON”.
OFF: The LED does not light up.
ON: The LED lights up.
ON/PWR ON: The LED lights up and the
transceiver turns on even if
the transceiver is OFF.
6. Press the [ENTER] soft key to store the selected level.
7. Press the [CLR/ ] key to return to radio operation.
9.3.4 KEY SETUP
The function assigned to the function screen Soft Keys can be changed (see
page 26 “8.12 Soft Keys”).
9.3.5 BACKLIT LEVEL
The backlight brightness may be adjusted in 5 levels.
1. Press and hold the [MENU/SET] key.
2. Press the [▲] or [▼] key to select “CONFIG”, then press the [SELECT]
soft key.
3. Select “BACKLIT LEVEL” with the [▲] or [▼] key, then press the [SE-
LECT] soft key.
4. Press the [▲] or [▼] key to select the de-
sired setting, from “1” to “5”, or “OFF”.
5. Press the [ENTER] soft key to store the se-
lected level.
6. Press the [CLR/ ] key to return to radio operation.
